STS Cabinet ECO-STS-C125-2/4/6IN

Name: STS Cabinet ECO-STS-C125-2/4/6IN
Brand: JIANGSU ELECNOVA ELECTRIC CO., LTD.

Elecnova ECO-STS-C125-2/4/6IN is a seamless on/off-grid switching cabinet designed for the 125kW rated power Elecnova all-in-one ESS cabinet within 20ms switching time. It enables on/off-grid switching for single or multiple parallel-connected application. Equipped with reserved ports for PV inverter power and critical loads connection, allowing for the normal operation of PV system and loads in grid outage condition.

Feature

Specifications

Recommended Compatible Products

SLD

Intelligent collaboration

Seamless on/off-grid switching within 20ms.

Highly Integration

Integrate STS, UPS, meter, breakers, ATS(optional) and other accessories in one system, compact and easy transportation.

Reliable

Leading brands selection of all equipments, safe and reliable.

Electrical Safety

Backup design and assurance of critical loads without interuption.

	ECO-STS-C125-2IN	ECO-STS-C125-4IN	ECO-STS-C125-6IN
ESS Side Parameters
Max. No. of ESS Connection	2 units	4 units	6 units
Max. ESS Current	2*250A	4*250A	6*250A
Rated ESS Power	2*125kW	4*125kW	6*125kW
Grid Side Parameters
No. of Grid Connection Port	1
Max. Grid Current	500A	800A	1600A
Rated Voltage	400V
Grid Voltage Range	400V±15%
Grid Type	3W+N+PE
Rated Frequency	50/60Hz
On/off-grid Switching Time	<20ms
PV & Loads Requirements
Max. PV&Loads Port Current	250A	630A	800A
Recommended Max. PV Inverter Power	170kW	430kW	550kW
Recommended Max. Load Power*	70% × ESS Power
Auxiliary Equipments Parameters
UPS	Standard
Maintenance Socket	Standard, 16A
Surge Protection	AC Type Ⅱ
Meter Accuracy	0.5S
ATS	Optional
General Parameters
Dimension(W×D×H)	800×1200×1800 mm	1000×1200×1800 mm	1200×1200×2200 mm
Altitude	3000m
Ambient Temperature	-15℃~45℃
Humidity	0~95%RH (non-condensing)
Cooling Method	Air cooling
IP Rating	IP54
Communication	RS485, Modbus TCP/IP
*Note: The value indicated herein is a recommended reference based on PF=0.7. When the load involves motors or other types of impact loads, it is recommended to equip the system with a soft starter. Please contact Elecnova for further technical support prior to order placement.
