Liquid-cooled Battery Cabinet ECO-B418LP-2N

Liquid-cooled Battery Cabinet ECO-B418LP-2N

The ECO-B418LP-2N is a free-standing battery cabinet featuring pack-level liquid cooling and cell-level temperature balancing. It maintains temperature differences within 3 °C between cells, enhancing temperature consistency and extending battery life. Its modular design offers flexible parallel configurations and can be paired with a centralized PCS to create a complete ESS solution that delivers higher energy density and significantly improves cost-effectiveness.

Feature
Specifications

Compact

1.7m2 footprint only, easy transportation & fast installation.


High Integration

Multiple units connected in parallel achieve MV/HV connection with PCS-boost containers.


Efficient Cooling

Optimal in-PACK duct design, achieve high-efficient cooling and low energy consumption.


Long Cycle Life

Over 8,000 times cycle life, excellent performance of battery system.


Flexible Expansion

Support seamless cabinets combination and flexible grid access.


Ultimate Safety

In-PACK fire warning and protection with aerosol, prevent heat diffusion and runaway.


ItemParameter
Cell TypeLFP / 314 Ah
Pack Configuration52.248 kWh / 1P52S
System Configuration418 kWh / 1P416S
Rated DC Voltage1331.2 V
DC Voltage Range1164.8 ~ 1497.6 V
Max. Charge/Discharge Rate0.5 P
Max. Depth of Discharge100% (25 ± 2 ℃)
Cycle Life≥ 8,000 cycles
CommunicationModbus TCP/IP
Fire Suppression SystemAerosol
Ingress RatingIP55
CoolingLiquid cooling+Forced air cooling
Operating Temperature-25℃~55℃ (Derating after 45℃)
Anticorrosion RatingC4 (C5 optional)
Humidity0~95% RH (non-condensing)
Altitude4500m
Dimensions (W*D*H)1,350*1,350*2,400 mm
Weight3,700 kg
Safety/EMCUN38.3, IEC62619, IEC63056, IEC62477-1, IEC61000-6-2/4
