EPS Cabinet ECO-EPS-C125-1/3/6IN

EPS Cabinet ECO-EPS-C125-1/3/6IN

Elecnova EPS (Emergency Power Supply) cabinet ECO-EPS-C125-1/3/6IN series is designed to enable on/off-grid switching for single unit or multiple parallel-connected units in emergency situations, with the switching time within 20 seconds, ensuring the operation of critical loads under off-grid conditions. The EPS cabinet supports both remote and on-site manual switching between on/off-grid modes, meeting the switching requirements of various application scenarios. In addition, the EPS cabinet allows the integration of grid-tied inverters and ensures their normal operation under off-grid conditions, thereby optimizing the system logic and overall efficiency of PV-plus-BESS projects. This enables the ESS to be applied in a wider range of complex application scenarios.

Feature
Specifications
Recommended Compatible Products
SLD

IP54 Outdoor Design

High protection rating for harsh environments.


Fast Deployment

Modular design for efficient wiring and installation.


Space Saving

Integrated structure with minimal size.


On/off-grid Switching

Built-in UPS provides backup power for on-grid and off-grid switching.



ECO-EPS-C125-1INECO-EPS-C125-3INECO-EPS-C125-6IN
ESS Side Parameters
Max. No. of ESS Connection136
Max. ESS Current250A3*250A6*250A
Max. ESS Power125kW3*125kW6*125kW
Grid Side Parameters
No. of Grid Connection Port1
Max. Grid Current315A800A1600A
Rated Voltage400V
Voltage Range400V±15%
Grid Type3W+N+PE
Rated Frequency50/60Hz
On/off-grid Switching Time≤20s
PV & Loads Requirements
Max. PV&Loads Port Current250A630A1250A
Recommended Max. PV Inverter Power170kW430kW860kW
Recommended Max. Load Power*70% × ESS Power
Auxiliary Equipments Parameters
UPSStandard
Surge ProtectionAC Type Ⅱ
Meter Accuracy0.5S
General Parameters
Dimension(W×D×H)600×800×1500 mm800×1000×2400 mm1000×1000×2400 mm
Altitude3000m
Ambient Temperature-10℃~40℃
Humidity0~95%RH (non-condensing)
Cooling MethodAir cooling
IP RatingIP54
CommunicationRS485, Modbus TCP/IP
*Note: The value indicated herein is a recommended reference based on PF=0.7. When the load involves motors or other types of impact loads, it is recommended to equip the system with a soft starter. Please contact Elecnova for further technical support prior to order placement.


  • ECO-E101WX

  • ECO-E241WP-2A

  • ECO-E261LP-2A


EPS Cabinet ECO-EPS-C125-1/3/6IN
