ECO-E101WX Air-cooled ESS Cabinet

ECO-E101WX Air-cooled ESS Cabinet

The all-in-one air-cooled ESS cabinet integrates long-life battery, efficient balancing BMS, high-performance PCS, active safety system, smart distribution and HVAC into one cabinet, enabling long-term operation with safety, stability and reliability. Through AC side parallel connection, it achieves agile deployment of ESS power station with flexible capacity expansion.


Feature
Specifications

1P fast charge/discharge rate.


Support DC-DC modular expansion to achieve PV access.


Support hybrid inverter (optional) to achieve integration of PV and ESS.


Features of ECO E100WX Air Cooled Ess Cabinet

DC Side
Cell TypeLFP 120Ah
Battery System1P264S
Rated Energy101kWh
Rated Voltage844.8V
Voltage Range739.2V-950.4V
AC Side
Rated Power100kW
Max. Power110kW
Nominal Voltage400Vac/3P+N+PE
Nominal Frequency50Hz/60Hz
THDi

≤3%

DC Ratio<0.5%Ipn
Power Factor-1lagging~1 leading
General
Efficiency

≥89%

Charge/Discharge Rate1P
DoD95% (25±2℃)
Cycle Life≥5000 cycles
Ingress RatingIP55
CoolingForced air cooling
Operating Temperature-25℃～55℃
Humidity0~ 95%RH. non-condensing
Altitude≤2.000m (derating above2,000m)
Dimensions (W*D*H)1,250*1,200*2,250 (mm)
Weight2,000kg
Fire SafetyAerosol
ConnectivityEthernet/RS485
ComplianceUN38.3. IEC62619, UL1973, UL9540, CE -EMC
